CCIE学习笔记之IP SLA
UDP Jitter：Measures round-trip delay, one-way delay, one-way jitter, one-waypacket loss, and connectivity testing of networks that carry UDP traffic, suchas voice.
ICMPPath Jitter：Measureshop-by-hop jitter, packet loss, and delay measurement statistics in an IPnetwork.
UDPJitter for VoIP：Measuresround-trip delay, one-way delay, one-way jitter, and one-way packet loss forVoIP traffic.
UDPEcho：Measuresround-trip delay of UDP traffic.
ICMPEcho：Measures round-trip delayfor the full path.
ICMPPath Echo：Measures round-trip delayand hop-by-hop round-trip delay.
HTTP：Measures round-trip timeto retrieve a web page.
TCP Connect: Measures the time taken to connectto a target device with TCP.
FTP: Measuresround-trip time to transfer a file.
DHCP: Measuresround-trip time to get an IP address from a DHCP server
DNS: MeasuresDNS lookup time
FrameRelay: Measurescircuit availability, round-trip delay, and frame delivery ratio
UDPJitter：
1.enable
2.configure terminal
3.ip sla monitor responder
1.enable
2.configure terminal
3.ip sla monitor operation-number
4.type jitter dest-ipaddr {hostname |ip-address } dest-port port-number
[num-packets number-of-packets] [ interval inter-packet-interval]
Table1 UDP Jitter Operation Parameters
UDPJitter Operation Parameter Default Configured Using:
Numberof packets (N) 10 packets type jitterdest-ipaddr command,
num-packets option
Payloadsize per packet (S) 32 bytes request-data-size command
Timebetween packets, in milliseconds (T) 20 ms type jitter dest-ipaddr command,
interval option
Elapsedtime before the operation repeats, in
seconds(F)
60seconds frequency (IP SLA) command
IP SLAs—Analyzing IP Servic e LevelsUsing the UDP Jitter Operation
Howto Configure the IP SLAs UDP Jitter Operation
5
CiscoIOS IP SLAs Configuration Guide
5.frequency seconds
6.exit
7.ip sla monitor schedule operation-number[ life { forever | seconds}] [start-time { hh:mm[:ss ] [ month
day| day month] | pending | now | after hh:mm:ss ] [ ageout seconds] [ recurring]
8.exit
9.show ip sla monitor configuration [operation-number]
例子：
ipsla monitor 1
type jitter dest-ipaddr 20.0.10.3 dest-port65051 num-packets 20
request-data-size 160
tos 128
frequency 30
ipsla monitor schedule 1 start-time after 00:05:00
ipsla monitor 2
type jitter dest-ipaddr 20.0.10.3 dest-port65052 num-packets 20 interval 10
request-data-size 20
tos 64
frequency 30
ipsla monitor schedule 2 start-time after 00:05:05
Analyzing Service Levels Usingthe VoIP UDP Jitter Operation
ip sla monitor 10
typejitter dest-ipaddr 209.165.200.225 dest-port 16384 codec g711alawadvantage-factor 2
owner admin_bofh
ip sla schedule 10 start-time now
Analyzing IP Service Levels Using the UDP Echo Operation
ip sla monitor 5
typeudpEcho dest-ipaddr 172.29.139.134 dest-port 5000
frequency 30
!
ip sla monitor schedule 5 start-time nowlife forever
Analyzing IP Service Levels Using the HTTP Operation
ip sla monitor 8
typehttp operation get url http://198.133.219.25
frequency 10
!
ip sla monitor schedule 8 life foreverstart-time now
IP SLAs TCP Connect
ip sla monitor 9
typetcpConnect dest-ipaddr 10.0.0.1 dest-port 23 control disable
frequency 30
tos128
timeout 1000
tagFLL-RO
ip sla monitor schedule 9 start-time now
!control enable作用让ip sla responder打开目标端口，但是本例中目标端口为众所周知端口，所以没必要打开
Analyzing IP Service Levels Using the ICMP Echo Operation
ip sla monitor 6
typeecho protocol ipIcmpEcho 172.29.139.134 source-ipaddr 172.29.139.132
frequency 300
request-data-size 28
tos160
timeout 2000
tagSFO-RO
ip sla monitor schedule 6 life foreverstart-time now
R1#show ip sla monitor statistics 20
Round trip time (RTT) Index 20
Latest RTT: 80 ms
Latest operation start time: *04:28:37.314UTC Fri Mar 1 2002
Latest operation return code: OK
Number of successes: 33
Number of failures: 0
Operation time to live: Forever
R1#show ip sla monitorcollection-statistics 20
Entry number: 20
Start Time Index: *04:12:37.378 UTC Fri Mar1 2002
Number of successful operations: 29
Number of operations over threshold: 0
Number of failed operations due to aDisconnect: 0
Number of failed operations due to aTimeout: 0
Number of failed operations due to a Busy:0
Number of failed operations due to a No Connection:0
Number of failed operations due to anInternal Error: 0
Number of failed operations due to aSequence Error: 0
Number of failed operations due to a VerifyError: 0
RTT Values:
RTTAvg: 68 RTTMin: 24 RTTMax: 148
NumOfRTT: 29 RTTSum: 1974 RTTSum2: 148310
Analyzing IP Service Levels Using the ICMP Path EchoOperation
ip sla monitor 7
typepathEcho protocol ipIcmpEcho 172.29.139.134
frequency 30
!
ip sla monitor schedule 7 start-time after00:00:30 life 300
R1#show ip sla monitor statistics 30
Round trip time (RTT) Index 30
Latest RTT: 60 ms
Latest operation start time: *04:24:45.578UTC Fri Mar 1 2002
Latest operation return code: OK
Operation time to live: Forever
R1#show ip sla monitorcollection-statistics 30
Entry number: 30
Start Time Index: *04:14:48.858 UTC Fri Mar1 2002
Path Index: 1
Hop in Path Index: 1
Number of successful operations: 23
Number of operations over threshold: 0
Number of failed operations due to aDisconnect: 0
Number of failed operations due to aTimeout: 0
Number of failed operations due to a Busy:0
Number of failed operations due to a NoConnection: 0
Number of failed operations due to anInternal Error: 0
Number of failed operations due to aSequence Error: 0
Number of failed operations due to a VerifyError: 0
Target Address 12.1.1.2
Analyzing IP Service Levels Using the ICMP Path JitterOperation
Router(config)# ip sla monitor 1
router(config-sla-monitor)# type pathJitterdest-ipaddr 172.17.246.20 num-packets 50
interval 30 targetOnly
! targetOnly keyword is used to bypass thehop-by-hop measurements. With this version of the command, echo probes will besent to the destination only
R1#show ip sla monitor statistics 50
Round trip time (RTT) Index 50
Latest RTT: 58 ms
Latest operation start time: *04:23:21.330UTC Fri Mar 1 2002
Latest operation return code: OK
---- Path Jitter Statistics ----
Hop IP 3.3.3.3:
Round Trip Time milliseconds:
Latest RTT: 58 ms
Number of RTT: 50
RTT Min/Avg/Max: 24/58/88 ms
Jitter time milliseconds:
Number of jitter: 40
Jitter Min/Avg/Max: 1/10/64 ms
Packet Values:
Packet Loss (Timeouts): 0
Out of Sequence: 0
Discarded Samples: 0
Operation time to live: Forever
In the following example, a Path Jitteroperation is configured to run over a××× using the VRF “red”
to the CE at 10.3.30.130:
Router# configure terminal
Enter configuration commands, one perline. End with the end command.
Router(config)# ip sla monitor 7
Router(config-sla-monitor)# type pathJitterdest-ipaddr 10.3.30.130
Router(config-sla-monitor-pathJitter)# vrfred
Router(config-sla-monitor-pathJitter)# exit
Router(config)# ip sla monitor schedule 7start-time now life forever
Analyzing IP Service Levels Using the FTP Operation
ip sla monitor 10
typeftp operation get url ftp://username:password@hostip/test.cap
frequency 30
!
ip sla monitor schedule 10 life foreverstart-time now
ip sla monitor 10
typeftp operation get url ftp://user1:abc@test.cisco.com/test.cap mode active
frequency 20
tos128
timeout 40000
tagFLL-FTP
ip sla monitor schedule 10 start-time01:30:00 recurring
!每天1:30am开始检测
Analyzing IP Service Levels Using the DNS Operation
ip sla monitor 11
typedns target-addr www.cisco.com name-server 172.20.2.132
frequency 60
exit
ip sla monitor schedule 11 life foreverstart-time now
Analyzing IP Service Levels Using the DHCP Operation
ip dhcp-server 172.16.20.3
!
ip sla monitor 12
typedhcp option 82 circuit-id 10005A6F1234
frequency 30
timeout 5000
tagDHCP_Test
!
ip sla monitor schedule 12 start-time now
! Note that DHCP option 82 is used tospecify the circuit ID
Multiple Operation Scheduling
ip sla monitor group schedule
group-operation-number operation-id-numbers
schedule-period schedule-period-range [ageout
seconds] [ frequencygroup-operation-frequency]
[ life { forever | seconds}]
[ start-time { hh:mm[ :ss ]
[ month day | day month]| pending | now |
after hh:mm:ss }]
Router# ip sla monitor group schedule 1 1-10 schedule-period 20
! The following example schedules IP SLAsoperations 1 to 10 in the operationgroup 1 with a schedule period of 20 seconds. By default, the fre quency isequivalent to the schedule period.
1. show ip sla monitor statistics
2. show ip sla monitor group schedule
3. show ip sla monitor configuration
Proactive Threshold Monitoring
Configuring Triggers for Round-Trip-Time Violations
ip sla monitor reaction-configuration operation-number react
rtt
[ threshold-type violation-condition]
threshold-value upper-threshold lower-threshold
[ action-type { trapOnly | triggerOnly | trapAndTrigger}]
Router# ip sla monitorreaction-configuration 10 react rtt
threshold-type immediate threshold-value5000 3000 action-type
trapAndTrigger
Configuring Triggers for Jitter Violations
ip sla monitor reaction-configuration operation-number
react { jitterAvg | jitterDSAvg |jitterSDAvg }
[ threshold-type violation-type]
threshold-value upper-thresholdlower-threshold
[ action-type { trapOnly | triggerOnly |trapAndTrigger}]
Example:
Router# ip sla monitorreaction-configuration 10 react
jitterAvg threshold-type immediatethreshold-value 5000 3000
action-type trapAndTrigger
! jitterAvg: average source-to-destinationjitter
! jitterDSAvg: averagedestination-to-source jitter
! jitterSDAvg : average ro und-trip jitter
Configuring Triggers for Packet Loss Violations
use the react PacketLossSD/ PacketLossDS in the ip sla monitor reaction-configuration command
Configuring Triggers for Mean Opinion Score Violations
use the react mos syntax in the ip slamonitor reaction-configuration command
Triggering SNMP Notifications: Example
Router(config)# ip sla monitor 1
Router(config-sla-monitor)# type jitter dest-ipaddr 209.165.200.225dest-port 3000 codec
g711alaw
Router(config-sla-monitor-jitter)# defaultfrequency
Router(config-sla-monitor-jitter)# exit
Router(config)# ip sla monitor schedule 1 start now lifeforever
Router(config)# ip sla monitorreaction-configuration 1 react rtt threshold-type immediate
threshold-value 3000 2000 action-typetrapOnly
Router(config)# ip sla monitor reaction-configuration 1 reactMOS threshold-type
consecutive 4 threshold-value 390 220action-type trapOnly
Router(config)# ip sla monitor logging traps
Router(config)#
Router(config)# snmp-server host 209.165.202.129 version 2cpublic syslog
! The following command is needed for thesystem to generate CISCO-SYSLOG-MIB traps.
Router(config)# snmp-server enable traps syslog
R2#show ip sla monitor statistics 2
Round trip time (RTT) Index 2
Latest RTT: 15 ms
Latest operation start time: *01:11:01.615UTC Fri Mar 1 2002
Latest operation return code: Overthreshold
Number of successes: 4
Number of failures: 5
Operation time to live: Forever
